Dynamic system

Adopting QSK19 electronic control engine, it has low fuel consumption, strong power, high reliability, and reliable global service;

The engine is equipped with an advanced modular common rail fuel system (MCRS), which meets the requirements of Euro IIA/China

Sichuan emission requirements:

The Saiclone dual pre filter intake system effectively prevents early engine failures.

Modular design

Adopting a hydraulic torque converter with locking function, the output torque can vary with the load, with strong load adaptability. Hydraulic transmission is used at low speeds and mechanical transmission is used at high speeds, which can save fuel by 10% -15% and has high fuel economy;

The normally closed brake has a parking brake function, which can effectively prevent the vehicle from sliding on slopes and has high safety;

Modular design of final drive, not attached to the main frame, can be assembled independently for easy maintenance.

Operational performance

Adopting a high-pressure hydraulic system with a system pressure of 21MPa, effectively reducing the volume of hydraulic components and providing good micro operation performance;

The operation of the working device adopts a pilot single handle device, which is flexible, lightweight, comfortable, and highly reliable;

The walking control adopts an electronic control single handle device, which can achieve the function of "manual and automatic fingertip shifting".

Driving and riding environment

Adopting a high-strength heptahedron cab, it has a large space, wide field of view, good airtightness, and effectively blocks external noise;

Adopting high-power heating and cooling air conditioning, the outlet layout is more reasonable, and the cooling and heating effect is good;

Standard high-end luxury interior, integrated with air conditioning ducts, control panel, tea cup holder, cigarette lighter, radio and other components;

Adopting luxurious B seats that can rotate 15 °, it is conducive to observing the state of the pine cone, with strong shock absorption and good comfort. It can achieve various adjustment functions and effectively reduce the fatigue intensity of the driver.

Ability to adapt to working conditions

The chassis system adopts a K-shaped suspension design with supporting wheels, which has a floating walking function and good driving comfort; Reduce the rigid impact on the entire machine and ensure a long service life; Increasing the grounding area under complex working conditions results in strong road adaptability and good traction performance.

Adopting a temperature controlled fan system, the fan speed can be intelligently controlled and adjusted as needed to improve fuel economy and save energy.

Equipped with high-quality, high-strength, and wear-resistant four wheel one belt, blade angles, tooth tips and other vulnerable parts, making it more durable
