power system

Cummins KTA19-C525 turbocharged diesel engine is powerful, efficient and energy-saving.

● The cylinder block and cylinder head are designed in an integrated way, which can effectively avoid water leakage and oil leakage.

● The number of parts is less than 25% compared with similar products, the failure rate is greatly reduced, the maintenance cost is lower, and the maintenance time is saved by more than 50% compared with similar products.

Transmission system

High-reliability power shift gearbox and final drive of planetary structure can be transmitted efficiently.

Power, high durability and high production efficiency.

● Automatically change the torque according to the change of external load, which has high fuel economy.

● Hydraulic components can absorb the impact load of the transmission device, which can increase the engine life by 1.5 ~ 2 times.

● The gearbox adopts multi-disc clutch, hydraulic combination and forced lubrication, and the central transmission adopts spiral bevel gear and splash lubrication.

Working hydraulic system

● The oil cylinder with new structure is adopted, and the seals and hydraulic hoses at key parts are imported products with higher service life and reliability. External working valve is more convenient for maintenance.
