基本参数(Basic parameters) | 性能参数(Performance specifications) | ||
整机重量 Total weight (kg ) | 10400 | 前进 1-4 档 Forward 1-4 gear (km/h ) | 2.6~ 10.4 |
发动机标定功率/转速 Engine rated power /speed (kw/ r/min) | 81/2300 | 后退 1-2 档 Reverse 1-2 gear (km/h ) | 3.7 ~6.7 |
发动机燃油消耗率 Fuel consumption of the engine (g/km.h ) | ≤220 | 接地比压 Land pressure (kPa ) | 54.4 |
发动机最大扭距 Engine max torque (N.m ) | 414 | ||
整机尺寸(Dimensions) | 作业范围及参数(Operating scope and parameters) | ||
总长(mm) Overall length | 4190 | 铲刀最大提升高度 Blade max lifting height( mm ) | 830 |
总宽度(mm) Overall width | 2935 | 铲刀入土深度 Blade max digging depth ( mm ) | 350 |
总高度(mm) Transport height | 3020 | 牵引装置/松土器(选装) Towing equipment/Ripper(optional) | 固定式/三齿 Fixed/three-toothed |
推土铲(宽) Bulldozer shovelW (mm ) | 2935 | ||
推土铲(高) Bulldozer shovel H(mm ) | 960 | ||
履带宽度 Caterpillar track board width mm | 450 | ||
1. This machine adopts a high-pressure common rail diesel engine jointly produced by Dongfang Hong and Ricardo of Britain, which meets the national two-phase emission requirements, with low noise, large torque, energy saving and environmental protection.
2. Four-wheel belts of well-known domestic brands, optimized walking mechanism and reinforced chassis, and customized profiles made of special materials have greatly improved the overall strength and impact resistance of the whole machine.
3. The hydraulic system adopts fluororubber ring, which has high sealing efficiency and high reliability. Hydraulic oil tank is separated from diesel oil tank, which is convenient for maintenance and repair;
4. All vehicles are equipped with standard LED headlights to improve night construction efficiency;
5. Install protective devices at the front ends of desert air filters and radiators to effectively improve heat dissipation performance, increase maintenance intervals, and better adapt to special working conditions such as coal yards, deserts and garbage dumps;
6. Adopt electronic monitoring electrical system to monitor the whole machine in real time to ensure its normal operation;
