Dynamical system

The Cummins KTA19-C525 turbocharged diesel engine has strong power and is efficient and energy-saving.

The cylinder block and cylinder head adopt integrated design, effectively avoiding the occurrence of water and oil leakage.

The number of parts is more than 25% less than similar products, the failure rate is greatly reduced, the maintenance cost is lower, and the repair time is saved by more than 50% compared to similar products.

Drive system

High reliability power shifting gearbox and planetary structure final drive can both efficiently transmit power

Power, with high durability and efficient production efficiency.

Automatically torque according to changes in external loads, with high fuel economy.

Hydraulic components can absorb the impact load of the transmission device, increasing the engine life by 1.5-2 times.

The gearbox adopts a multi plate clutch, hydraulic combination, and forced lubrication form, while the central transmission adopts a spiral bevel gear and splash lubrication form.

Working hydraulic system

Adopting a new type of structural oil cylinder, seals and hydraulic hoses in key parts are original imported products,

Higher service life and reliability. External working valve, more convenient for maintenance.

Attachment of work tools

The frontworking device is a standard semi U-shaped shovel, with a high-strength box structure and high-performance materials to ensure that the shovel has strong cutting force and excellent durability, and can cope with various complex working environments. 16m ³  The ultra large capacity shovel is an ideal and efficient operating device for earthwork construction and bulk material transportation.

The rear working device is a single tooth loosening device with adjustable angle, which has super strong penetration force. The high-strength crossbeam, bracket, and tooth rod and tooth tip that have undergone multiple heat treatments provide more durable reliability and service life. Not only can it be used for loosening clay and hardened frozen soil, but it can also be used for stripping hard working surfaces such as gravel, compacted salt mines, and developed rock layers.

Structure

The main frame with a full box structure is made of high-performance materials and high-strength castings, which have high performance

Capable of bearing impact loads and resisting bending and torsion, supporting equipment in harsh working conditions

High intensity continuous operation and high-quality welding ensure that the main frame has a full life cycle.

Chassis system

The K-suspension floating driving system and pivot chassis structure can effectively reduce impact loads

The impact on the transmission system, improving the traction performance and lifespan of the vehicle.

Advanced shock absorption system can effectively absorb impact loads and improve the stability of the entire vehicle under complex working conditions.

The main section sealed lubrication track has a long service life and is easy to disassemble and assemble.

Driving and riding environment

The cab has a beautiful appearance, with a large internal space and a wide field of view. The installed shock absorber can reduce vibration, while cooperating with the air conditioning system, making operators safer and more comfortable at work.

The overall cast instrument panel ensures a reasonable layout of electrical, instrumentation, and air conditioning, with a beautiful appearance.

According to ergonomics, the driver's seat and armrest can be easily adjusted up, down, forward and backward. The speed control, steering, and throttle control are placed on the left side, and the working device control is placed on the right side. The PPC pilot control system is used to make the control process more lightweight and flexible, reducing fatigue.

Security

Safety warning lights, reverse alarm bells, horns, good braking, and distinctive overall painting. Effectively protect the safety of peripheral personnel and enhance the safety guarantee of all-weather operations; Seat belts

The entire machine is equipped with a large number of handrails and safety signs to provide safety protection for operators.

The side shield can effectively protect the engine and radiator from blockage and damage caused by external particles, making the whole machine more beautiful.

The standard antifreeze can increase boiling point and decrease freezing point, effectively preventing the formation of scale in the engine and radiator, which is beneficial for engine cooling and protection.

In addition, anti rollover frames with anti roll and anti fall functions can be optionally installed to avoid accidents and injuries to operators.
