Overall length

11161mm

Overall width

3200mm

Transport height

3347mm

Overall width of upperstructure

3195.3mm

Overall height of cab

3293mm

Shoe width

600mm

Track gauge

2600mm

Min. ground clearance

565mm

Tail swing radius

3438mm

Track ground length

5872mm

Track length

5044mm

Working Range

Max. digging height

11056mm

Max. dumping height

6905mm

Max. digging depth

6755mm

Max. vertical wall digging depth

6452mm

Max. digging reach

10645mm

Min. swing radius

4418mm

Dynamical system

Engine Model

6HK1X

Cylinders

3*115*125

Displacement

7.79

Power

212kw/2000rpm

Cooling method

inter-cooling

Hydraulic System

Operating Pressure

36MPa

Q max  L/MIN

2X330

Pump

Linde

Valve

Linde

Walking motor

Rexroth

Shape

Load sensing system

performance parameter

（SAE）Bucket Capacity

1.62m³-1.82m³

Climbing ability

70%（35°）

Maximum digging force

230KN

Travel speed

5.0/3.0

Unit swing speed

9.7r/min

Hydraulic tank capacity

580
