发动机额定功率power

124KW/2050rpm

铲斗容量Bucket Capacity

1.0-1.4m³

液压系统Hydraulic System

林德Linde

行走马达Walking motor

日本纳博NABTESCO

发动机型号Engine Model

康明斯Cummins QSB6.7

B

总宽度mm

Overall width

2980

C

总高度（动臂顶部）mm

Transport height

2970

D

上部宽度mm

Overall width of upperstructure

2860

E

总高度（驾驶室顶部）mm

Overall height of cab

3040

F

标准履带板宽度mm

Shoe width

600

G

轨距mm

Track gauge

2380

H

最小离地间隙mm

Min. ground clearance

440

I

尾部回转半径mm

Tail swing radius

2710

J

履带接地长度mm

Track ground length

3480

K

履带长度mm

Track length

4260

斗容m³

Bucket capacity

1.1-1.3m³

额定功率KW/rpm

Rated Power

124/2050

行走速度（高/低km/h）

Travel speed(H/L)

5.5/3.3

回转速度rpm

Swing speed

11

爬坡能力（35°）

Gradeability

70%

接地比压kpa

Ground pressure

46.5

铲斗挖掘力KN

Bucket digging force

150

斗杆挖掘力KN

Arm digging force

109

B

最大卸载高度mm

Max. dumping height

7110

C

最大挖掘深度mm

Max. digging depth

6620

D

最大垂直臂挖掘深度mm

Max. vertical wall digging depth

5980

E

最大挖掘距离mm

Max. digging reach

9875

F

最小回转半径mm

Min. swing radius

3040

G

最小回转半径时的最大高度mm

Max. Height at Min. swing radius

8060

用于矿山爆破后的硬岩、风化岩及碎石等的挖掘和装载作业

It is used for excavation and loading of hard rock, weathered rock and gravel after blasting

岩石

1.1

¤

用于松软泥土、干沙等松散物料的挖掘或装载作业

Used for digging or loading loose materials such soft and dry sand

标准

1.2

¡

用于松软泥土、干沙等松散物料的挖掘或装载作业

Used for digging or loading loose materials such soft and dry sand

加大

1.3

¡
