发动机型号engine model | WEICHAI 8M33 |
形式for | 电控高压共轨 水冷 V型八缸 涡轮增压 Electronically controlled high-pressure common rail water-cooled V-type eight-cylinder turbocharging |
排量（L）Displacement | 26.1 |
额定功率（kW/rpm） rated powe | 680/1800 |
液压系统形式 Hydraulic system form | 活塞泵+齿轮泵+冷却泵 Piston pump+gear pump+cooling pum |
额定工作流量（L/min） Rated working flow | 3x530 |
斗杆挖掘力（kN） Bucket digging force | 532 |
铲斗挖掘力（kN） Bucket digging force | 610 |
行走速度（km/h）Walking speed | 2.4/3.5 |
| 牵引力（kN）traction | 745 |
爬坡能力gradeability | 70％（35°) |
最高回转速度（r/min）Maximum rotation speed | 5.5 |
操作重量（kg）Operating weight | 120000 |
接地比压（kPa）Grounding specific pressure | 147 |
铲斗容量（m³)dipper capacity | 7.5-10 |
燃油箱容量（L）fuel capacity | 1450 |
冷却系统（L）cooling system | 156 |
发动机机油量（L）Engine oil quantity | 100 |
| 液压油箱/系统容积（L）Hydraulic tank/system volume | 610/1350 |
工作装置最小回转半径Minimum turning radius of working device | 6765 |
| 接地长度（运输时)Grounding length (during transportation) | 8490 |
| 总高（至动臂顶部）Overall height (to the top of boom) | 6130 |
| 总宽 | 5385 |
| 总高（至驾驶室顶部）Overall height (to the top of cab) | 4475 |
| 配重离地间隙Ground clearance of counterweight | 1900 |
| 最小离地间隙min. ground clearance | 1070 |
| 尾部回转半径Tail radius of gyration | 5100 |
| 履带长度 Track length | 6500 |
| 轨距gauge | 3900 |
| 履带宽度Track width | 4600 |
| 标准履带板宽度 Standard track shoe width | 700 |
| 回转转台宽度（不含走台/含走台)Width of rotary table (excluding platform/including platform) | 3490/5385 |
| 回转中心至后端部距离 Distance from center of rotation to rear end | 4960 |
最大挖掘高度Maximum excavation height | 12480 |
最大卸载高度Maximum unloading height | 8065 |
最大挖掘深度Maximum excavation depth | 8165 |
最大垂直挖掘深度Maximum vertical excavation depth | 4600 |
最大挖掘距离Maximum excavation distance | 13875 |
地平面的最大挖掘距离Maximum excavation distance of ground plane | 13485 |
1. Weichai 8M33 engine, low speed, high torque, working speed 150 rpm lower than that of competing products, large fuel consumption economic zone, lower fuel consumption, power up to 680kW, 20% better than that of competing products, and high working efficiency.
2.7.5-10m³ large bucket capacity, meeting the requirements of different working conditions.
3. Linde 300cc large displacement main pump is 7% better than similar products.
4. Fully electronically controlled hydraulic system and autonomous programming technology realize perfect matching of power and hydraulic pressure, with faster response speed and better maneuverability.
