shipping length

8350(mm)

Total height during transportation

3005(mm)

Transport width

2550(mm)

Tire center distance

2650(mm)

Counterweight ground clearance

1100(mm)

umber of tires

8*900-20

Boom length

4250(mm)

Stick length

2200(mm)

Working Range

Max.Digging Height

7350(mm)

Max.Dumping Height

5300(mm)

Max.Digging Depth

4505(mm)

Max.Digging radius

7505(mm)

Maximum lifting height of earth shovel

400(mm)

The maximum digging depth of dozer

160(mm)

Dynamical system

Model

QSB3.9—C125

power

 93 KW

Cooling method

Water-cooling

Hydraulic System

Operating Pressure

31mpa

Main pump

K3V63DTP-HNOW

Hydraulic valve

AV170  Korea

Travel motor

Plunger

Shape

Load Sensing System

Performance parameter

（SAE）Bucket Capacity

0.6m³

Climbing ability

20°

Maximum digging force

8500N

Travel speed

28KM/h

Unit swing speed

9-11r/min

Hydraulic oil capacity

180L

Hydraulic tank capacity

220L

Braking mode

4WD hydraulic brake

Stabilizers

Legs
