shipping length

4400(mm)

Total height during transportation

2400(mm)

Upper shelf / chassis width

1530/1600(mm)

Track width

1230(mm)

Track length

1500(mm)

Min.ground clearance

227(mm)

Boom length

2400(mm)

Stick length

1250(mm)

Working Range

Max.Digging Height

4650(MM)

Max.Dumping Height

3050(MM)

Max.Digging Depth

2545(MM)

Max.Digging radius

4630(MM)

Minimum radius of gyration

1820(MM)

Maximum lifting height of earth shovel

359(MM)

The maximum digging depth of dozer

268(MM)

Min Tail swing radius

1170(MM)

Dynamical system

Engine Model

LD490

Power

34KW

Cooling method

water-cooling

Hydraulic System

Operating Pressure

22mpa

L/MIN

90L/min

pump

柱塞Plunger

Walking motor

A2F63 speed plunger

performance parameter

Bucket Capacity

0.26m³

Climbing ability

35°

Maximum digging force

5560N

Travel speed

≤20KM/h

Unit swing speed

8-10r/min

Hydraulic tank capacity

22L
