shipping length

6346(mm)

Total height during transportation

2800(mm)

Transport width

2200(mm)

Tire center distance

2400(mm)

Counterweight ground clearance

1035(mm)

umber of tires

8*750-16

Boom length

3560(mm)

Stick length

1900(mm)

Working Range

Max.Digging Height

6550(mm)

Max.Dumping Height

5100(mm)

Max.Digging Depth

3380(mm)

Max.Digging radius

6590(mm)

Maximum lifting height of earth shovel

300(mm)

The maximum digging depth of dozer

100(mm)

Dynamical system

Engine Model

Yang dong

Power

60/55KW

Cooling method

Water-cooling Turbo

Hydraulic System

Operating Pressure

22mpa

Main pump

SGP1A2XFZH9

Shimazduo

Hydraulic valve

Korea

Shape

Load Sensing System

performance parameter

（SAE）Bucket Capacity

0.36m³

Climbing ability

30°

Maximum digging force

8200N

Travel speed

35KM/h

Unit swing speed

9-11r/min

Hydraulic oil capacity

90L

Hydraulic tank capacity

120L

Parking brake

Air break

service brake

Kill

Stabilizers

Legs / optional
