| SH60 Technical Specification | ||
| Basic parameter | Operating weight | 5500KG |
| Bucket capacity | 0.22m³ | |
| Engine | Engine model | Yanmar4TNV94L |
| Cylinder | 4 | |
| Displacement | 3.054 | |
| Engine power | 37.5KW // 2200rpm | |
| Engine oil capacity | 12L | |
| hydraulic pump | Rexroth | |
| Hydraulic | control valve | Kawasaki |
| swing or travel | Nachi | |
| Cylinder | Japan's KOBELCO | |
| Rotating support | Japan's KOBELCO | |
| cabin | Japan's KOBELCO | |
| Performance parameter | Max. Gradeability | 35° |
| Ground pressure | 32.5Kpa | |
| hydraulic pressure | 22 Mpa | |
| Traveling speed | 2.4-4.5 km/h | |
| The main pump rated flow | 150L/min | |
| Bucket digging force | 48KN | |
| arm digging force | 32KN | |
| Working scope | Max.digging height | 5635mm |
| Max.digging depth | 3800mm | |
| Max. vertical wall digging depth | 2700mm | |
| Max.dumping height | 4000mm | |
| Min. swing radius | 2465mm | |
| Appearance size | Overall dimensions(L*W*H) | 5850×1900×2580mm |
| Width of platform | 1885mm | |
| Width of undercarriage | 1900mm | |
| Width of crawler | 400mm | |
| Clearance under counterweight | 680mm | |
| Min. ground clearance | 385mm | |
| Min. tail swing radius | 2800mm | |
| Standard size | Boom length | 3000mm |
| Arm length | 1600mm | |
| bucket width | 600mm | |
| Fuel tank capacity | 115L | |
| Hydraulic tank capacity | 85L | |
Excavator shall be suitable for work on multiple surfaces such as grass, pavement or stone without damaging the surface or machine and cutting edge type back fill blade suitable for quick clear up of job sites and for general grading and leveling. The excavator shall have high performance, low noise and elegance design. The equipment must be suitable for excavating solid and semisolid garbage from ditch, clogged drain, excavating soil / sand / stone through operating even on a sloppy or rough surface area.
