HOME >> PRODUCT >> Excavators >> Electric Excavator
| 型号 | model | SH15 |
| 重量 | weight | 1500KG |
| 铲斗容量 | Bucket capacity | 0.025cbm/120Kg |
| 铲斗宽度 | Bucket width | 380mm |
| 驱动电机 | Drive motor | |
| 功率 | power | 6.5KW |
| 额定电压 | Rated voltage | 72伏 |
| 行走速度 | Walking speed | 3.5km/h |
| 主要尺寸 | Main dimensions | |
| 总尺寸 | Overall size | 2550x940x1380mm |
| 轨距 | Gauge | 770mm |
| 轨道总长度 | Total track length | 1090mm |
| 平台离地间隙 | Platform ground clearance | 380mm |
| 最小尾部摆动半径 | Minimum tail swing radius | 733mm |
| 底盘宽度 | Chassis width | 940mm |
| 轨道宽度 | Track width | 180mm |
| 底盘离地间隙 | Ground clearance of chassis | 380mm |
| 轨道高度 | Track height | 320mm |
| 工作范围 | Scope of work | |
| 最大挖掘深度 | Maximum excavation depth | 1650mm |
| 垂直挖掘深度 | Vertical excavation depth | 1375mm |
| 最大挖掘高度 | Maximum excavation height | 2610mm |
| 最大卸载高度 | Maximum unloading height | 1850mm |
| 最大挖掘半径 | Maximum excavation radius | 2850mm |
| 最小旋转半径 | Minimum radius of rotation | 1330mm |
| 推土铲最大提升高度 | Maximum lifting height of bulldozer | 345mm |
| 推土铲最大挖掘深度 | Maximum digging depth | 255mm |
Shandong Province. The company specializes in R&D and production of various series of excavators
